Low Profile Telescopic Fork

40 mm Low-Profile Section for Restricted Installation Space



The RFKB-250×40 series is a single-extension low-profile plate-type telescopic fork developed for applications with limited vertical clearance, narrow aisles, and compact automated storage equipment.

Its main structural feature is the 250 × 40 mm flat section. The 40 mm profile reduces the vertical installation space required by the fork body and allows it to work where available fork clearance is limited. This makes the Low Profile Telescopic Fork suitable for low-clearance stacker cranes, space-restricted automated storage equipment, and special mechanical handling stations.

While the fork has a low height, its section is 250 mm wide. The wider supporting surface helps distribute the load across a larger transverse area during material handling. This gives the product a different application focus from narrow-section fork designs.

The RFKB-250×40 series uses a single-extension structure and does not have to be installed as a pair. One fork can operate independently. This can be useful where machine width does not allow two forks to be installed or where a mechanical station requires pickup from only one side.

A single-fork arrangement also removes some of the mechanical synchronization work required between paired forks, making inspection and replacement more direct.

Multiple fork length and stroke combinations are available. Fork body lengths range from 650 mm to 1450 mm, with corresponding strokes from approximately 750 mm to 1550 mm. Buyers can select a suitable specification according to stacker crane structure, storage depth, and the required pickup position.

This allows the Low Profile Telescopic Fork to be selected around actual machine geometry rather than using one fixed length for every warehouse project.

10Yares of experience
in one-stop service

Telescopic forks require controlled machining dimensions, straightness, and assembly consistency. For this reason, the mechanical manufacturing capability of the supplier is an important part of project matching.

Anhui Rayo Automation Technology Co., Ltd. operates gantry machining centers, CNC machining centers, laser cutting machines, CNC lathes, and bending machines. The company can carry out processes from precision component machining through equipment assembly and commissioning.

Its engineering teams also cover mechanical design, electrical control, and system integration. When the RFKB-250×40 is used with a stacker crane or another automated mechanism, the fork dimensions can be considered together with installation space, required stroke, and workstation conditions. This helps improve the fit between the fork and the complete machine structure.



300+

Global Clients

99+

Intellectual Property Rights

4+

Overseas Offices Estabiished

6000+

Project Deliveries

When selecting this series, buyers should first confirm available installation height, required extension distance, load width, and the mechanical structure where the fork will be installed.

The RFKB-250×40 is particularly suited to applications where installation height is restricted but a relatively wide supporting surface is still required. Its procurement value therefore comes from the combination of low profile, selectable extension distance, supporting stability, and straightforward maintenance.

Ruiyou applies standardized internal processes and standardized operating procedures. The company holds CNAS accreditation and SGS third-party certification at the company level. For customized Low Profile Telescopic Fork projects, support can extend from solution design and mechanical manufacturing to installation, commissioning, and after-sales service.
